KEY UCD FEATURES

  • - Design Flexibility
    • Multi-lamp capability
    • Wattage choices
  • - Longevity
    • Up to 30,000 hour lamp life
    • Up to 60,000 hour ballast life
  • - Environmentally Friendly
    • Uses minute traces of mercury (Hg) – Actual mercury content is <0.001 mg/lamp.
      For Example:
      • 600+ UCD lamps contain the same amount of mercury as a single metal halide lamp.
      • 1800+ UCD lamps contain the same amount of mercury as a single induction lamp.
    • Small lamp size means fewer raw materials needed for manufacturing and packaging.
  • - Wide Operating Range: -50o C / -58o F to 85o C / 185o F
  • - Easily Retrofittable: The compact lamp and slim ballast design allows the UCD system to be readily
    installed in most fixtures. This is a distinct advantage when compared to most other systems, which are not easily accommodated within existing fixtures.



LAMPS

  • - Instant Start / Restrike
    • Full illumination within 60 seconds
  • - Highest Quality of Light
    • > 80 Color Rendering Index (CRI)
  • - Lumen Maintenance
    • 91% at 50% of lamp life
    • ≥ 80% at end of lamp life
  • - Up to 108 Lumens/W






BALLASTS

  • - High Ballast Efficiency
    • Approximately 89%
  • - Unstable Power Input Correction Sensor
    • Able to withstand 10 kV and 10 kA power surges
    • ANSI C 62.41 Transient Surge Suppressor Category C
